Product Features
✅ Rated current 30A, supports DC 12V – 1500V high voltage system
✅ Optional coil voltage: 12V / 24V, suitable for a variety of control systems
✅ Normally open contacts to improve system safety
✅ Optional auxiliary contacts (NO/NC) for easy status monitoring and linkage control
✅ High insulation voltage & low contact resistance to ensure stable system operation
✅ Long mechanical life & excellent arc extinguishing ability
✅ Compact structure, flexible installation, strong adaptability
✅ Efficient coil, retentive power is only 4.0-4.2W
✅ The joint way of the coil is very convenient
✅ Dimension: 51.6×35.6×46.2mm
✅ Weight: 115g
✅ IP Grade: IP67
✅ Mechanical life: 2x105 cycles
✅ Approval: UL, CE, TÜV
Application scenarios
Energy storage system (BESS): battery pack high voltage on-off control
New energy vehicles (EV/HEV): main circuit, high voltage system, charging equipment control
⚡ Charging piles & DC fast charging stations: high voltage circuit connection and disconnection
☀️ Photovoltaic power generation system (PV): inverter and battery high voltage management
Industrial automation & DC control cabinet: high voltage DC bus control and protection
Rail transit, power equipment: high voltage system electrical isolation and safety protection
Applications include electric vehicles, fast charging piles, battery switching and backup, high voltage DC voltage switching control, circuit protection and safety control.
