EV Fast Chargers & DC Fast Charging Stations | 60kW to 320kW
Looking for high-performance EV fast chargers for commercial or public charging networks? Our range of DC fast charging stations is designed to support the next generation of electric mobility, with power levels ranging from 60kW, 80kW, 120kW, 160kW up to 320kW, meeting the needs of various electric vehicles including passenger EVs, electric buses, trucks, and fleets.
Whether you're deploying fast charging stations for electric vehicles in urban areas, highway corridors, or industrial sites, our chargers ensure fast, reliable, and safe power delivery with high efficiency and smart charging capabilities.
Multiple Power Options: 60kW / 80kW / 120kW / 160kW / 320kW
High Compatibility: CCS2, CHAdeMO, and GB/T options available
Smart Charging: OCPP protocol support, remote monitoring, and load balancing
Modular Design: Easy maintenance and scalable for future expansion
Weatherproof & Durable: Suitable for indoor and outdoor installations
Applications: EV charging stations, commercial fleets, highway service areas, parking lots, energy storage systems
Maximize charging speed, optimize energy use, and build a smarter, greener charging network with our DC fast chargers. Explore our product series to find the perfect EV fast charging solution tailored to your project needs.
| EV Fast Charger 160KW | ||
| Input Feature | Input voltage | 400Vac(±15%)，3 Phase+PE+N |
| Grid frequency | 45Hz～65Hz | |
| Power factor | ≥0.95 (6KW≤Output power≤15KW)；≥0.98 (15KW≤Output power≤30KW) | |
| Output Feature | Max output power | 160KW (the sizes 60kW, 80kW and 120kW are also available) |
| Output voltage range | 100Vdc～1000Vdc | |
| Max output current | 532A | |
| Rated current | 160A | |
| Voltage stabilized accuracy | ≤±0.5％(Stabilized voltage state, input voltage 323Vac～456Vac, output voltage 200Vdc～1000Vdc, output current 0～rated current value) | |
| Current stabilized accuracy | ≤±1％(Stabilized current state, input voltage 323Vac～456Vac, output voltage 200Vdc～1000Vdc, output current 20% rated current～100％ rated current) | |
| Ripple factor (Peak to peak) | ≤1%(Stabilized voltage state, input voltage 323Vac～456Vac, output voltage 200Vdc～1000Vdc, output current 0～rated current value) | |
| Protection & Function | Output, input over-voltage and under-voltage proteciton; over-temperature protection; lightning protection function; over-current protection; insulation detection function | |
| Cooling Method | Fan cooling | |
| Application Environment | Working Temperature | -40℃～＋75℃, Output derating above 60℃ |
| Storage Temperature | -40℃～＋75℃ | |
| Relative humidity | ≤95％RH, non-condensing | |
| The altitude | ≤2000m without derating, >2000m, the working temperature will decrease by 1℃ for every 100 rise | |
| MTBF | >500,000 hours | |
| Physical dimension | L700mm*W600mm*H1900mm | |
| Configuration Standard | Numbers of module installation | 40KW module *4 |
| Single gun( with 5 meters' cable) | GB/T;CCS 1;CCS 2;Chademo | |
| Dual gun(with 5 meters' cable) | GB/T+CCS 1;GB/T+CCS 2;GB/T+Chademo;CCS 1+CCS 2;CCS 1+Chademo;CCS 1+CCS 2 (power can be distributed equally) | |
| Charging Method | Card swiping, background start up, startup at site,etc | |
| Platform & Interface | OCPP1.6J;4G/LAN | |
EV Fast Chargers & DC Fast Charging Stations | 60kW to 320kW
Looking for high-performance EV fast chargers for commercial or public charging networks? Our range of DC fast charging stations is designed to support the next generation of electric mobility, with power levels ranging from 60kW, 80kW, 120kW, 160kW up to 320kW, meeting the needs of various electric vehicles including passenger EVs, electric buses, trucks, and fleets.
Whether you're deploying fast charging stations for electric vehicles in urban areas, highway corridors, or industrial sites, our chargers ensure fast, reliable, and safe power delivery with high efficiency and smart charging capabilities.
Multiple Power Options: 60kW / 80kW / 120kW / 160kW / 320kW
High Compatibility: CCS2, CHAdeMO, and GB/T options available
Smart Charging: OCPP protocol support, remote monitoring, and load balancing
Modular Design: Easy maintenance and scalable for future expansion
Weatherproof & Durable: Suitable for indoor and outdoor installations
Applications: EV charging stations, commercial fleets, highway service areas, parking lots, energy storage systems
Maximize charging speed, optimize energy use, and build a smarter, greener charging network with our DC fast chargers. Explore our product series to find the perfect EV fast charging solution tailored to your project needs.
| EV Fast Charger 160KW | ||
| Input Feature | Input voltage | 400Vac(±15%)，3 Phase+PE+N |
| Grid frequency | 45Hz～65Hz | |
| Power factor | ≥0.95 (6KW≤Output power≤15KW)；≥0.98 (15KW≤Output power≤30KW) | |
| Output Feature | Max output power | 160KW (the sizes 60kW, 80kW and 120kW are also available) |
| Output voltage range | 100Vdc～1000Vdc | |
| Max output current | 532A | |
| Rated current | 160A | |
| Voltage stabilized accuracy | ≤±0.5％(Stabilized voltage state, input voltage 323Vac～456Vac, output voltage 200Vdc～1000Vdc, output current 0～rated current value) | |
| Current stabilized accuracy | ≤±1％(Stabilized current state, input voltage 323Vac～456Vac, output voltage 200Vdc～1000Vdc, output current 20% rated current～100％ rated current) | |
| Ripple factor (Peak to peak) | ≤1%(Stabilized voltage state, input voltage 323Vac～456Vac, output voltage 200Vdc～1000Vdc, output current 0～rated current value) | |
| Protection & Function | Output, input over-voltage and under-voltage proteciton; over-temperature protection; lightning protection function; over-current protection; insulation detection function | |
| Cooling Method | Fan cooling | |
| Application Environment | Working Temperature | -40℃～＋75℃, Output derating above 60℃ |
| Storage Temperature | -40℃～＋75℃ | |
| Relative humidity | ≤95％RH, non-condensing | |
| The altitude | ≤2000m without derating, >2000m, the working temperature will decrease by 1℃ for every 100 rise | |
| MTBF | >500,000 hours | |
| Physical dimension | L700mm*W600mm*H1900mm | |
| Configuration Standard | Numbers of module installation | 40KW module *4 |
| Single gun( with 5 meters' cable) | GB/T;CCS 1;CCS 2;Chademo | |
| Dual gun(with 5 meters' cable) | GB/T+CCS 1;GB/T+CCS 2;GB/T+Chademo;CCS 1+CCS 2;CCS 1+Chademo;CCS 1+CCS 2 (power can be distributed equally) | |
| Charging Method | Card swiping, background start up, startup at site,etc | |
| Platform & Interface | OCPP1.6J;4G/LAN | |
